Rated Input voltage =AC380/15%
Rated input capacity =Tig:5.0KVA / MMA:7.6KVA
Rated Output U2 =Tig:18.8V / MMA:29.2V
Rated duty cycle =35%
Welding current range =20-230A
voltage =70V
Arc force current range =0-60A
Decay time =0-5s
Exhaust time =1-10s
Arc method =High frequency arc strike
Effectiveness =85%
Power Factor =0.93
Protection class =IP21S
Insulation class =F
Dimensions =500 215 380mm
Weight = 16kg
